MDPE 12.5 Bar

Available in coils with diameters 16 to 140mm and pressures 6.3 to 25 bar.

Standard coil sizes available: 50, 100 and 200m rolls.

Other diameters are pressure ratings also available in straight lengths. Suitable for drinking water and in-line bloat applications.

Proudly made in New Zealand by RD Manufacturing

All Rural Direct Branches sell a full range of Philmac compression fittings and AGRU electro-fusion fittings to suit MDPE Pressure Pipe.

MDPE 12.5 Bar Pressure Pipe				#colspan#	#colspan#	#colspan#
Rural Pressure OD Pipe PN12 PE100 – Black Pipe Blue Stripe
DN (OD) mm	Product Code	Coil Length in m	Pressure Rating
25	MD25.PN12.025	25	PN12.5
	MD25.PN12.050	50
	MD25.PN12.100	100
	MD25.PN12.200	200
32	MD32.PN12.050	50	PN12.5
	MD32.PN12.100	100
	MD32.PN12.200	200
40	MD40.PN12.050	50	PN12.5
	MD40.PN12.100	100
	MD40.PN12.200	200
50	MD50.PN12.050	50	PN12.5
	MD50.PN12.100	100
	MD50.PN12.200	200
63	MD63.PN12.050	50	PN12.5
	MD63.PN12.100	100
	MD63.PN12.200	200
75	MD75.PN12.050	50	PN12.5
	MD75.PN12.100	100
90	MD90.PN12.050	50	PN12.5
	MD90.PN12.100	100
110	MD110.PN12.050	50	PN12.5
	MD110.PN12.100	100
